Off grid 5Kva 48V solar energy solar home system, Solar panel roof top system

FOB Reference Price:Get Latest Price
US $2,299-2,600 / Sets | 1 Set/Sets solar energy system (Min. Order)
Report Suspicious Activity
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Model Number:
Output Voltage (V):
Load Power (W):
Solar Power (W):
Work Time (h):
>8 hours
Solar Panel:
Poly250w/30v *9pcs
MPPT 60A 48V * 1Pc
200AH/12V *4pcs
48V-220V , 5000VA 50HZ
460KG / SET
2 years for the whole set .
Full Power:
Overloads; Over charge; Low voltage;
Supply Ability
Supply Ability:
10000 Set/Sets per Month solar energy system
Packaging & Delivery
Packaging Details
Carton packaging/Wooden Packages
Lead Time :
within 5 days if have stock
Related Products

1.5kva solar power system

Mini order quantity: 1 Sets, more cheaper FOB Price: US $ 835-860/Set

3.5kva solar power system

Mini order quantity: 1 Sets, more cheaper FOB Price: US $ 1,480-1,520/Set

10kva solar power system

Mini order quantity: 1 Sets, more cheaper FOB Price: US $ 6,400-6,500/Set

3.5kva integrated solar system

Mini order quantity: 1 Set, more cheaper FOB Price: US $ 1,650/Set

5kva integrated solar system

Mini order quantity: 1 Set, more cheaper FOB Price: US $ 2,650/Set

10kW-100kw solar solution

Mini order quantity: 1 set, more cheaper FOB Price: Depends on configuration

Product Introduction

Off grid 5KW 48V solar energy solar home system, Solar panel roof top system

Brief Introduction

Solar power system is a new kind of energy-saving and environmentally friendly system. It is a system which uses PV modules to convert sunlight into electricity. It's made up of PV module, controller, battery and inverter. It is mainly used in some remote and power-unstable areas.
Solar PV systems are very reliable and clean source of electricity that can suit a wide range of applications such as residence, industry, agriculture, livestock, etc.
Solar power system is mainly used to drive all kinds of household electrical appliances and office equipment, to solve the power shortage situation without electricity or people living or working electricity problem.

Products Details

Main Advantages

1. All systems has LCD digital display. (Can see the system working condition, such as system voltage, system power, charge current, etc)
2. All systems have AC and DC output, and also have AC charger function for backup.
3. When the electricity off, it can switch automatically and take use of battery power to run load. When power on it also can switch automatically and take use of main power(utility electric/generator electric), at the same time charging battery.
4. The inverter is pure sine wave inverter, it can load inductive load such as air condition very smooth.
5. Each component has single chip detect which protected itself.(Over-voltage protection, low-voltage alarm, overload protection, over-heat protection, short-circuit protection, etc)

6. Battery for option, there are many kinds of battery you can use in the system, not only using our battery.
7. Felicitysolar solar power system can update configuration easily, we will provide a professional advice for you according to your inquiry.
8. Easy installation, we will provide the install files and data to you.
9. Competitive price with high quality solar power system, professional technology, and more function than other company.
10. Safe and beautiful, our engineer designed the system with professional technology.
11. Long lifespan, trouble-free and no maintenance because of the system components high quality.

Product Parameters
FL-POWER-10000VA 48V
Solar Power
GEL Deep Cycle Battery
200AH/12V *1pc
200AH/12V * 2 pcs
200AH/12V * 4 pcs
200AH/12V *8pcs
200AH/12V * 12 pcs
PWM 30A12V*1pc
MPPT 60A 24V*1pc
MPPT 60A 48V*1pc
MPPT 60A 48V*2pcs
MPPT 60A 48V*2pcs
Full Power
1500VA 12V*1pc
3500VA 24V*1pc
5000VA 48V*1pc
7500VA 48V*1pc
10000VA 48V*1pc
Battery Box
2 pcs batteries in one box
4 pcs batteries in one box
4 pcs batteries in one box
*2 pcs box
4 pcs batteries in one box
*3 pcs box

PV Copper Wire
FL-POWER-1500VA 12VA:
6MM² 10M 2 pcs; 6MM² 1M 2pcs; 16MM² 0.8M 2 pcs
FL-POWER-3500VA 24V:
6MM² 10M 2 pcs; 6MM² 1M 2pcs; 16MM² 0.8M 3 pcs
FL-POWER-5000VA 48V:
6MM² 20M 2 pcs; 6MM² 1M 2pcs; 16MM² 0.8M 3 pcs; 16MM² 0.2M 2 pcs
FL-POWER-7500VA 48V:
6MM² 25M 4 pcs; 6MM² 1M 4pcs; 16MM² 0.8M 8 pcs; 16MM² 0.2M 6 pcs
FL-POWER-10000VA 48V:
6MM² 25M 4 pcs; 6MM² 1M 4pcs; 16MM² 0.8M 13 pcs; 16MM² 0.2M 8 pcs

Parts Details

(1)Solar cell module
Solar modules is a major part, but also the value of the highest solar power system components, its role is to convert the sun's radiant energy to DC power.
(2)Solar Charge Controller
Solar Charge Controller, also known as "PV Controller", whose role is issued by the solar cell module to adjust and control power, maximize battery charge, and played a battery charge protection, over-discharge protection effect. Place in a large temperature difference, solar controller should have temperature compensation function.
Its main task is battery energy storage in order to ensure that the load-day electricity at night or rainy.
(4) Battery Box and Wires
Battery box is helpful for storage and usage of battery. And we choose special PV wires for the solar power system.
(5)Off-grid inverters
Off-grid inverter is the core component of off -grid power system, is responsible for converting direct current to alternating current for AC load use. In order to improve the overall performance of photovoltaic power generation system to ensure long-term stable operation of the power station, the inverter performance is very important.

Installation Manual

We have many certification, such as CE, SONCAP, ISO, etc.

Application Cases

We have did many solar power system projects in the past year. In Africa, South East Asia, Mid East, South America... you can see our solar power system in many place. We have got a lots of experiences to build a solar power system project.

Why Choose us?

1, Many years experience
Our company found in 2007 and start doing solar business for a long time. We have exported our products to many countries, such as Africa, Mid East, Asia, America, etc.
2, Strict Quality Control
For each order, strict inspections will be put in place for each procedure during their processing. The negative products will be ironed out before shipping
3, Stable suppliers
We have cooperated with many accessory suppliers for many years, so we can get cheaper and high quality accessories and thus we can give you a low price and high quality products.
4, Smooth Shipping
We have partnership with excellent shipping forwarders, therefore we can promise fast delivery and have the goods well protected.
5, Customers from all over the world
We have enough experience about foreign trade and our clients can be found in many countries
6, Fast reply
We will respond your question as soon as possible!
